Dual Rail Conveyor
10 heating zones
Dimension 6160x1539x1490mm
Weight APPROX:3050KG
Product description: 10 Zones Dual Rail SMT Reflow Oven KTE-1000D, Dual Rail Conveyor, 10 heating zones, Dimension 6160x1539x1490mm, Weight APPROX:3050KG
10 Zones Dual Rail SMT Reflow Oven KTE-1000D
Advantage:
1. Totally meet various requirements for the lead free processing.
2. WindowsXP operation system, Chinese/English can be swtiched online.
3. Standard air oven, Patent air system, using hot air convection conduction heat faster, more efficient compensation.
4. PLC+PID closed loop control to achieve high prectise temperature control and repeatable profiles.
5. Dual temperature sensors and dual safety control, system shall cut off the power while abnormal alarm.
6. Modular design to get quick and simple maintenance so that reducing the maintenance time & cost.
7. Double-track dual-speed, single machine cost, double production capacity, energy saving up to 65%
Model | KTE-1000D | Control | Industrial computer |
10㎡/min×2 | Color | Grey | |
Control system | |||
Electricity supply | 3P 380V/220V 50/60HZ | Temp. control range | ±1℃（static state） |
Start power | 38KW | Temp. control method | PID +SSR drive |
Consumption power | 12KW | PCB temperature deviation | ±1.5℃ |
Speed control | Inverter adjust | Data save | All profiles can be saved |
Warm up time | Apprx.30minute | Abnormal alarm | High, low temp. alarm |
Conveying system | |||
Rail structure | 2 Sectional structure | Rail fixed method | 1,4 fix 2,3 moving |
Chain | Stuck-free type | Conveying height | 900±20mm |
PCB Max. width | 50-400mm | Conveying method | Mesh+ chain |
Component height | Top/bottom 25mm | Conveying speed | 300-2000mm |
Conveying direction | Left to right | Lubrication | Automatic |
Cooling system | |||
Cooling method | Forced air cooling | ||
Heating features | |||
Heating zones | ＜15min | ||
Heating zone temp. control accuracy | ±1℃ | ||
PCB temp. deviation | ±1.5℃ | ||
Empty to full load heat balance respond time | ≤20 s | ||
